Operating voltage Max (V)

60

Output Voltage Range (V)

adjustable from 1V to VIN

Output current (A)

Up to 3

Synchronous (integrated highside and lowside mosfet)

Yes

Operating quiescent current (uA)

24

Shutdown quiescent current (uA)

1.3

Light load mode

PFM

Fsw (KHz)

200 to 2500

EMI Performance

Spread Spectrum Reduces Peak Emissions

Other functions

Enable pin；

Power Good Indicator,；

Internal Compensation,；

Adjustable Soft Start and Tracking Capability；

Synchronization to external clock：

Protection

Accurate Peak and Valley Current Clamp,；

Output short-circuit protection with hiccup mode,；

Accurate Vin UVLO protection；

Over-temperature shuntdown and recovery,；

Package

TSSOP-EP16

Rating

AEC-Q100 Grade1

Operating junction temperature

-40 to 150

Functional safety supported

Functional Safety Supported
